Optimanufacturing T60-1001-C8-1A User Manual

SOP-TN-002 Rev. Q
T60 Operations and Service Manual
14
FIG. & UNITS USABLE
INDEX DESCRIPTION PER ON
NO. ASSY CODE
-34
AN960-3L . WASHER
2/4
-35
T60059 . INDICATOR, Dial 1 A
T60057 . FACE, Dial-British Model 1 A,C
T60060 . INDICATOR, Dial 1 B
T60067 . FACE, Dial-British Model 1 B,D
-36
COML #0908100-03 . BALL BEARING, 0.093 dia cres 1
-37
COML #0913200-02
. PIN, Groove type # 4, 1/16 dia x 5/16
inch long
1
-38
T60025 . CAP, Handle lock 1
-39
T60028 . SPRING, Handle latch 1
-40
T60024 . PLUNGER, Handle lock 1
-41
T60021 . Frame Assy 1
T60074 (not shown) . . BEARING 1
T60011 . . FRAME 1
T60033 . . PIN-FRAME 8
-42
T60054 . TEST BAR ASSY, Calibrating 1
T60053 . . TAG 1
T5036 . . TEST BAR 1
MS20470AD2-3 . . RIVET, 1/6 dia x 3/16 inch long 1
-43
T5138-60 . CARRYING CASE ASSY 1
0922100-88 . . BLACK CASE 1
T5185-51 . . INSERT CUSHION 2
T5184-01 . . CUSHION, T60 1
-44
WI-CU-002 . . INSTRUCTIONS SHEET, Operating 1 A, B
WI-CU-003 . . INSTRUCTIONS SHEET, British Model 1 C, D
-45
T60039 . LABEL, INSTRUCTIONS 1
-46
T60040 . LABEL, NAMEPLATE 1
-47
SOP-TN-002 . . OPERATION AND SERVICE MANUAL 1 ALL
-48
T60007 . . WRIST BAND 1 ALL
PART NUMBER
. Denotes non-subassembly or final component part. . . Denotes subassembly parts.
OPTI Manufacturing Corp.
Road 992 Km 0.3. Luquillo Industrial Park,
Luquillo, PR 00773-2581 USA
Phone: (787) 889-2285 / Fax: (787) 889-2805 fax
Copyright  . OPTI Manufacturing Corp. All Rights Reserved
Point of Contacts:
General Info: info@optimanufacturing.com
Sales/Shipment: sales@optimanufacturing.com
Technical Support/RMA is: jorge@optimanufacturing.com
For the latest revision of this manual, refer to our website.
http://www.optimanufacturing.com
