SOP-TN-002 Rev. Q
T60 Operations and Service Manual
13
Table 6 Part List
FIG. & UNITS USABLE
INDEX DESCRIPTION PER ON
NO. ASSY CODE
6-
T60-1001-C8-1A TENSIOMETER ASSY, Cable REF. A
T60-1001-C9-1A TENSIOMETER ASSY, Cable REF. B
T60-1002-C8-00 TENSIOMETER ASSY, Cable-British Model REF. C
T60-1002-C9-00 TENSIOMETER ASSY, Cable-British Model REF. D
-1
COML # 0901100-55 . SCREW, 4-40 x ½ inch long Phillips oval head 2
-2
T60012 . COVER, Head 1
-3
T5033-3 . SHIM, Clip, 0.003 inch thick A/R
T5033-5 . SHIM, Clip, 0.005 inch thick A/R
T5033-10 . SHIM, Clip, 0.010 inch thick A/R
-4
T5018 . CLIP 2
-5
T5013 . BLOCK, Riser 1
-6
T5020 . CLIP, Mainspring 2
-7
T5019-1 . MAINSPRING 1 A,C
T5019-3 . MAINSPRING 1 B,D
-8
T5034 . WASHER 2
-9
T60032 . SCREW, Spring adjusting 1
-10
T541 . SPRING, Follower riser 1
-11
COML # 0901100-48
. SCREW, 4-40 x 3/16 inch long hexagonal
socket head cup point black oxide
2
-12
T60031 . POST, Shaft 1
-13
T60026 . SHAFT, Indicator 1
-14
COML #0901100-99
. SCREW, 10-32 x 5/16 inch long socket head
1
-15
T60018 . PIN, Center 1
-16
T60022 . INDICATOR, Cable size 1 A,B
T60058 . INDICATOR, Cable size-British Model 1 C,D
-17
T60019 . WASHER, Center pin 1
-18
T60068 . WASHER, Spacer 3
-19
T60014-1 . HANDLE ASSY 1
-20
T60037 . WASHER, Spacer 1
-21
T60070 . LINER, Pin 1
-22
T60071 . LINER, Roller 1
-23
T60023 . YOKE ASSY 1
-24
T537 . SECTOR 2
-25
T60052 . WASHER 6
-26
T60030 . ROLLER, Guide yoke 1
-27
AN531-4RF6
. SCREW, 4-40 X 3/8" thread cutting Phillips head 82º
C sunk
2
-28
T60008 . PLATE 1
-29
T60050 . SPRING, Trigger 1
-30
T60035 . SPRING, Switch 1
-31
T60048 . PIN, Switch spring 1
-32
T60006 . SHAFT, Switch 1
-33
MS35207-203
. SCREW, Indicator, 2-64 x 1/4" long round head
Phillips Recess UNF-2A
2
PART NUMBER
