Optimate TM500 - Charging Process and LED Indicators

12V
CHARGE SAVE
MAINTAIN
TEST - - -
BATTERY SAVING
CHARGER-MAINTAINER
LEAD-ACID & LIFEPO
4
12V
LIFEPO4LEAD-ACID
12.8V12.8V
LFP
12V
DC DC
DC DCDC DC
Model: TM500 v2
OUTPUT/SORTIE/SALIDA/LEISTUNG/
USCITA/UITGANG/UTSPÄNNING/
SAIDA:
12V 2A
DC IN / Courant d'entrée directe /
Gelijkstroom-ingang / entrada de
corriente directa / ingresso diretto di
corrente /entrada decorrente direta /
Likström ingång / Gleichstrom-Eingang
12-16V 2.7A max
DC IN
LED #1 - SOURCE BATTERY LOW (<11V)
LED #2 - Reverse polarity
LED #3 - LOW VOLT SAVE (≥ 2V)
LED #4 - CHARGE & OPTIMIZE
LED #5 - GREEN: TEST & MAINTAIN
LED #6 - RED: TEST & MAINTAIN
1
2
3
4
5
6
12V SOURCE BATTERY
/ DC SUPPLY
12V / 12.8V BATTERY FOR
CHARGING & MAINTENANCE
25%
50%
75%
100%
12.8V
12.6V
12.4V
12.2V
12.0V
10%
10%
30%
13.0V
13.1V
50%
75%
13.2V
13.6V
100%
LiFePO4
AGM
25%
50%
75%
100%
10%
STD
11.8V
% : VOLTS
TABLE 1
2
