SPECIFICATIONS
Television System ............................................................................... NTSC Standard Color Signal
Recording System................................................................................. Four-Head Double Azimuth
Tape Width .............................................................................................................................
1
/
2
Inch
Tape Speed:
SP............................................................................................. 1.31 Inch/second (33.35 mm/s)
LP ............................................................................................. 0.65 Inch/second (16.67 mm/s)
EP.............................................................................................. 0.43 Inch/second (11.12 mm/s)
Tuner Channels:
VHF .................................................................................................................................... 2–13
UHF .................................................................................................................................. 14–69
CATV ....................................................................................................................................125
RF Converter ................................................................................................Built-in VHF Converter
Converter Output ...................................................................................................... Channel 3 or 4
Terminals:
Antenna Input ................................................................................................ VHF/UHF: F Type
Antenna Output ............................................................................................. VHF/UHF: F Type
Video Input/Output.......................................................................................... Phono Connector
Audio Input/Output.......................................................................................... Phono Connector
Video Output Level .............................................................................................................. 1.0 V
p-p
Video Output Impedance .......................................................................................................... 75 Ω
Audio Output Level ............................................................................................................... –8 dBV
Audio Output Impedance .......................................................................................................... 1 kΩ
Video Input Level ............................................................................................................ 0.5-2.0 V
p-p
Video Input Impedance ........................................................................................................... 50 kΩ
Audio Input Level ................................................................................................................ –10 dBV
Audio Input Impedance........................................................................................................... 47 kΩ
Video S/N Ratio (weighted):
SP...................................................................................................................................... 42 dB
EP...................................................................................................................................... 40 dB
Audio S/N Ratio:
Regular Audio (weighted)
SP...................................................................................................................................... 43 dB
EP...................................................................................................................................... 40 dB
Hi-Fi Audio (Model 60 only): (Dynamic Range):
SP.................................................................................................................... More than 90 dB
LP .................................................................................................................... More than 90 dB
EP.................................................................................................................... More than 90 dB
