Optimus CTR-116 - Manual Recording; Using an External Microphone

19
MANUAL RECORDING
Manual recording is like VOX recording, except you control
when recording begins and ends. Set
VOX
to
OFF
, then press
RECORD
to begin recording. Press
STOP/EJECT
to stop
recording, or press
PAUSE
in to temporarily stop recording.
USING AN EXTERNAL MICROPHONE
The CTR-116’s built-in microphone works well in most situa-
tions, but you can connect an external microphone (not sup-
plied) with a
1
/
8
-inch (3.5-mm) plug to the recorder’s
MIC
jack.
This automatically disconnects the built-in microphone.
Note:
Your local RadioShack store sells a variety of micro-
phones.
Set
VOX
to
HIGH
or
LOW
for VOX recording, or to
OFF
for manu-
al recording.
If the microphone has an ON/OFF switch for remote control,
connect the microphone to the CTR-116’s
REMOTE
and
MIC
jacks. Then you can start and stop recording with the switch on
the microphone.
