M130 Version 1.0 Page 12 of 23
M130
8x8 Audio Matrix
General Specifications:
Power Supply
Selectable switch: 110 ~ 220 VCA or
220 ~ 240 VAC, 50 / 60 Hz
Power Consumption
50 W
Weight
8,3 kg
Dimensions
482 (W) x 132 (H) x 280 (D) mm
Temperature / Humidity
0 ~ 40 ºC / < 95 %
Specifications can be changed without notice.
4. REMOTE MICROPHONE M132M
4.1. Front panel
1. Gooseneck microphone input.
Insert the microphone into this XLR connector and it will get a 24 VDC phantom power.
2. Audio output level meter.
Shows the volume level microphone output.
