Optiview Mini Speed Dome Camera - Specification

28
MODEL
10X A/F CAMERA MODULE
3X PAN FOCUS MODULE
PAN /TILT
Pan Rotation Angle
360˚ Endless
Pan Speed
Manual
100˚ ~ 150˚/sec
Preset
Max 200˚ /sec
Tilt Rotation Angle
0˚ ~ 90˚
Tilt Speed
Manual
100˚ ~ 150˚/sec
Preset
Max 200˚ /sec
System Accuracy
0.02˚
FUNCTIONS
Presets
165 positions with a 16-character label available for each position
with different speed steps
Group Tour
Max. 8 Programmable group tours (each one consisting of up to 60 preset steps
with different steps)
Auto scan
Programmable Auto scan
Pattern
8 Programmable Patterns (total 480 seconds)
Privacy Zone
4 privacy zones
-
Sector
8 selectable Sectors with 16 characters
Password Protection
Yes
Alarm Input
4 alarms OFF/NC/NO (with various programmable states)
Alarm Actions
Activate preset, Group scanning or Patterns
Auto Flip
ON / OFF
OSD Menu
Multiple Languages on screen
Communication
RS-485
Protocol
Pelco D/P
POWER
Consumption (12V DC)
9W Max (Heater Type 15W)
Consumption (24V AC)
18W Max (Heater Type 30W)
Power Supply(12V DC)
DC12V 750mA (Heater Type DC12V 1.2W)
Power Supply(24V AC)
AC 24V 650mA (Heater Type AC24V 1.3W)
OTHERS
Construction
die-casting , Anti-vandal dome cover
Dimensions
158.8φ (D) * 163.0mm(H)
Weight
1.5 kg
Motor Type
Stepper Motor
Micro Steps
1/4 Step
Storage Temperature
-10℃ ~ 60℃
Operating Temperature
0℃ ~ 50℃
Certifications
CE, FCC
CAMERA
MODULE
Image Sensor
1/4" Sony Super HAD CCD
Total
Pixels
NTSC
811(H) * 508(V) 410K
PAL
795(H) * 596(V) 470K
Number Of
Effective
Pixels
NTSC
768(H) * 494(V) 380K
PAL
752(H) * 582(V) 440K
Horizontal resolution
More Than 500TV Lines
More Than 520TV Lines
Lens
Optical
10x Optical Zoom
(F=3.8 to 38mm)
3x Optical Zoom
(F=1.9~2.8, f=4.1~7.3mm)
Digital
10x (100x with optical)
-
Day & Night (ICR)
Auto/ Day/ Night
-
Min. Shooting Distance
0.35m(Wide)/0.8m(Tele)
0.32m(Wide)/1.5m(Tele)
Digital Slow Shutter
2/4/8/16/24/32/64/128/ OFF
-
Min.
illumination
Normal
mode
0.7Lux (50IRE)
1.0Lux (50IRE)
Night
mode
0.02Lux (ICR On)
Luminance S/N Ratio
More than 50dB
Video Output
VBS:1.0Vp-p/75 Ohm
BLC
ON / OFF
Flickerless
NTSC
ON / OFF (1/100)
PAL
ON / OFF (1/120)
WHITE BALANCE
AWB/ATW/INDOOR/ OUTDOOR
AWB only
SPECIFICATIONS
