Optoma DS316L User Manual

ES526/EX536/EX531/CB2800/ES526L/EX536L/DS316L
Condential
I
Preface
This manual is applied to ES526/EX536/EX531/CB2800/ES526L/EX536L/DS316L
projection system. The manual gives you a brief description of basic technical information
to help in service and maintain the product.
Your customers will appreciate the quick response time when you immediately identify
problems that occur with our products. We expect your customers will appreciate the
service that you offer them.
This manual is for technicians and people who have an electronic background. Please
send the product back to the distributor for repairing and do not attempt to do anything that
is complex or is not mentioned in the troubleshooting.
Notice: The information found in this manual is subject to change without prior notice. Any
subsequent changes made to the data herein will be incorporated in future edition.
ES526/EX536/EX531/CB2800/ES526L/EX536L/DS316L Service Manual
Copyright July. 2010
All Rights Reserved
Manual Version 4.0

Optoma DS316L Specifications

General

Matrix size	0.55 \
Projection distance	1.2 - 12 m
Vertical scan range	24 - 85 Hz
Horizontal scan range	15.3 - 91.1 kHz
Projection technology	DLP
Contrast ratio (typical)	4000:1
Screen size compatibility	27.49/303.12 \
Projector native resolution	SVGA (800x600)
Keystone correction, vertical	-40/40 °
Throw ratio	1.95 - 2.15:1
Digital zoom	1.1 x
Focal length range	21.8 - 24 mm
Aspect ratio	4:3, 16:9
Dimensions (WxDxH)	286 x 192 x 84 mm
Power requirements	100-240V, 50-60Hz
Connectivity technology	Wired
F-number (relative aperture)	2.41
Lamp power	185 W
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	4000 h
RMS rated power	2 W
AC (power) in	Yes
Serial interface type	RS-232
Power consumption (standby)	1 W
Power consumption (typical)	233 W
Certification	RoHS
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	5 - 85 %
Placement	Ceiling

Weight and Dimensions

Weight	2300 g
