Optoma EP910 - Table of Contents

EP910
Table of Contents
Chapter 1 Introduction 1-1
Highlight 1-1
Compatible Mode 1-4
Chapter 2 Disassembly Process 2-1
Equipment Needed 2-1
Appearance 2-1
Disassemble Lens Cover and Lamp 2-2
Disassemble Top Cover 2-3
Disassemble Keypad Board 2-4
Disassemble Vent 2-5
Disassemble Rear Cover and Main Board 2-6
Disassemble Ballast 2-7
Disassemble Optical Module 2-8
Disassemble Fan 2-9
Disassemble Color Wheel 2-10
Disassemble DMD Chip 2-11
Disassemble LVPS 2-12
Chapter 3 Troubleshooting 3-1
Equipment Needed 3-1
Main Procedure 3-1
Chapter 4 Function Test and Alignment Procedure 4-1
Test Equipment Needed 4-1
Service Mode 4-1
Test Condition 4-1
Inspection Procedure 4-2
ii
