English
12
Installation
Power Cord1.
HDMI Cable *2.
RCA Component Cable for YPbPr *3.
VGA to RCA Component Cable for YPbPr *4.
Emitter Cable * 5.
12V DC Plug*6.
Composite Video Cable *7.
Connect to Video
Due to the
difference in ap-
plications for each
country, some
regions may have
different acces-
sories.
12V Trigger is
programmable
trigger.
For more detailed
information about
connecting to the
3D emitter and 3D
glasses, please
refer to their
user’s guides.
Use high speed
HDMI cable to
connect Blue-ray
3D player.
* Optional Acces-
sory
NOTE
HDMI 1 HDMI 2
VGA YPbPr
Y G Pb B Pr R
VIDEO SERVICE RS-232
12V Trigger
3D SYNC
Out (5V)
POWER
E62405SP
R
DVD Player, Set-top Box,
HDTV receiver
1
7
3
6
5
4
Composite Video Output
2
3
DVD Player, Set-top Box,
HDTV receiver
3D Glasses

Other manuals for Optoma Projector
