optrel e3000 multi bay charger
optrel e3000 multi bay charger 4551.013
Tecnical Data
Battery Ports: 6
Indicator Lamps:
- LED red = the battery is emptyie batterie ist leer
- LED green = the battery is fully charged
Input: AC 100 - 240V ~ 0.4A 50-60 Hz
Output: 16.8V 0.8
For internal use only!
OFF/On
-For all the slots with properly connected
batteries, a control light will turn on (red for an
empty battery and green for a fully charged).
-Once the control lamp with a connected battery
turns green, the battery should be removed from
the power supply.
-Not used charging cables should be placed in
the designated sockets.
-Even If a slot is empty and / or not connected, the
indicator light turns green.
