Page 5
MICROS Workstation 8 I/O View
Figure 1-3: MICROS Workstation 8 I/O View
USB C Out (5V/9V/15V)
Power to CFD (5V, 2A)
Micro USB LAN Port
Gigabit LAN
USB C Power In
Power from adaptor
CMOS reset button
Not end user use
