use a can
of freeze-spray to locate the
offending
com-
ponent. Freeze-spray is also very
useful in
tracking
down
intermittents
.
CIRCUIT DESCRIPTION (WITH TROUBLESHOOTING
HINTS):
General
:
The
418
is divided
into four
major
blocks.
In
order of
signal
passage
these
are:
1)
The
input buffer and broadband
AGC;
2)
The
program-controlled pre-emphasis,
which
serves
as
a
high-frequency limiter;
3)
The
de
-emphasis
and output stage; and
4)
The power
supply.
Left and
right audio paths are identical, and
share
a
common control
circuit.
Only
the left channel, plus
the
control circuit will be described.
Input Buffer and Broadband
AGC:
The
signal enters
the
41
8A
in
balanced form,
and is
applied to
IC201,
an LF356
low-noise
FET-input opamp
configured
as a
gain-of-one
differential amplifier.
When
both
(+)
and
(-)
inputs are driven
from
source impedances
very small
compared to
50K
(such
as
600 ohms), the
am-
plifier is essentially
insensitive to
signal components
that
appear
equally on
both
(+)
and
(-)
inputs (such
as
hum),
and responds with
full
unity
gain to the
difference
bet-
ween
the
(+)
and
(-)
input.
Thus it
serves
as
an "active
transformer.
"
If
signals in excess
of
+21
dBm are
applied to the input,
this
amplifier will clip
regardless of the setting
of the
in-
put attenuator,
and an
external balanced loss pad
must be
employed before
the
41
8A
input.
The
gain control element is
a
P-channel
junction
field
effect
transistor, IC2I6A,
operated
as a
voltage variable
resistor. This
FET
shunts the lower
leg of
the voltage di-
vider R213,
223
to reduce the gain. Note that the va-
lues of
R213
and R223 are selected at
the factory to com-
plement the particular
FET
employed. If
IC216
is ever
replaced
(a
highly
unlikely occurrence),
the factory
should
be consulted.
The audio level across
the
FET
is
16 mv at the thresh-
old of limiting. This
level
is
amplified back
up
by
IC205,
a
709 opamp
configured for
34.5 dB
non-inverting gain.
IC205
is
frequency-compensated by
C2I3,
217,
219 and
R215, 217. The
output of
IC205
is clamped to
+2.4
volts
by the diode strings CR20I,
203, 205,
207,
209,
211, 213,
215 to prevent damage to
1C
207 in
the event
that excessive input signal
is applied.
The gain of
IC205
is determined by
R219,
221,
and
C225. R229
forces
a
constant
current to flow from the
output of
IC205
to the
-15
supply, thus forcing the
output stage of
IC205 to
operate class
A to
eliminate
crossover distortion.
The output of
IC205
is applied to
the
two halves of
IC207,
a
711
dual comparator. The inputs of
IC207 also
receive reference voltages of +and
-1
.2 volts derived
from voltage dividers
R294-297. If the peak level
of
the output of'
IC205
attempts to exceed
+1
.2 volts,
1C
20 7 turns on,
producing
a
pulse
which
is coupled
through
C266
and
CR228
to
Q21
1
.
Q21 1 is turned
on
by the
pulse, and discharges
C267
and
C268
through
CR230 and CR229 respectively. This voltage
change
across
C267
is coupled to the gate
of
the
FET
through
R231
,
thereby
decreasing the resistance of the
FET
and
decreasing
the
gain
of the
circuit until the overload
at
the
output
of
IC205
is removed. Attack time of the
cir-
cuit is determined by
R288 and
is
about 2 ms. The
re-
lease time is
a
very complex function of the
nature of
the
program,
and
is determined
by
the proprietary
cir-
cuit inside
the
module. Basically, the module
derives
a
voltage based
on
the previous history of the
program
and applies the voltage
to
one end of
the
RELEASE
TIME
control,
P211.
The other end of
P211 is connected to
C268, and permits
C268
to charge at
a
rate
controlled
by
the module in conjunction with the setting
of
P211.
In addition, the network
CR231
and
R289
provides
de-
layed release to
assure low distortion at low frequencies.
This
is accomplished
as follows:
When gain reduction
occurs,
both
C267
and
C268
are
discharged
to
the
same voltage
because
CR230
and
CR229
have substantially
identical voltage drops.
However,
C267
must
charge
(release) through
CR231
and
R289.
R289
provides virtually no
short-term release
because
of
its high
value. Therefore,
C267
cannot charge until
C268
has charged
sufficiently to overcome the turn-on
voltage of
CR231
.
This time delay eliminates the usual
sawtooth ripple on the
control voltage, thus drastically
reducing distortion.
The collector
of
Q211 is clamped to ground
through
the
base-emitter junction of
Q210.
This
way,
the
gate
of the
control
FET
cannot be
forward-biased. In addi-
tion,
when
Q210
conducts, it turns on
the front -panel
OVERLOAD LED,
thus indicating
that
the
permissable
15
dB gain reduction range has been
exceeded.
P210
determines
the quiescent
gate voltage
of
the
control
FET,
and is
adjusted
to
pinch this
FET
off when
no
gain reduction
occurs.
Thus
maximum gain
is extre-
mely
stable,
and
no
distortion is introduced by
the
FET.
The
control
FET
is
contained in
a
package with four
matched, monolithic
FET's. The second
FET
is used
to
control the
gain of the right
channel; the third
FET is
operated
with
DC across it to control the
GAIN REDUC-
TION meter.
The
fourth
FET
is not used.
The DC
gain
reduction signal
is
amplified by
IC219,
a
non-inverting
opamp
.
5
