Parts
List
Parts are listed by part class by assembly
in Reference Designator order
except
for certain widely used common parts such as:
Fixed Resistors
3/8"
Square Trimmer Resistors
Signal Diodes
which are described generally under the appropriate
heading and which must be
examined
to
determine the exact value.
OBTAINING
SPARE PARTS
Because special or subtle characteristics
of certain components are
exploited in
order to produce an elegant design
at a
reasonable cost, it is
unwise to make
substitutions for listed
parts. It
is
also
unwise to ignore
notations in the
Parts
List
indicating
"Selected" or
"Realignment Required" when
replacing
components.
In such cases, the factory
should be consulted if
optimum
performance
is to be maintained.
Orban normally maintains an inventory of tested, exact
replacement spare
parts
to
supply any
present or
normal future demand quickly at
nominal cost.
When ordering
parts from the factory, we
will need all
of
the
following
information:
-
The Orban
Part
Number, if
ascertainable
-
The
Reference Designator for a defective
component
-
A
brief description of the part
-
From the
Serial Label on the rear:
-
The exact
Model Number
-
The
Serial
Number
-
The
"M" number, if any
Orban can supply standardized
Spare
Parts
Kits
for this
product during its
production life.
Consult your
dealer or the
factory for the consist
of
such
kits and their
prices.
Parts for this unit have been chosen from the
catalogs of well-known
manufacturers for
ease
in future maintenance. The U.S.
headquarter addresses
are listed at the end of the
Parts List. Most manufacturers have
extensive
distribution facilities throughout the
world and may often be contacted
through local offices.
