KIT F CODE COMPONENTS QUANTITY
KIT F OC2 DROPPER. 31.6mm
FOR ALL DROPS
X0910000
F.1
ACTUATOR LOCKNUT
1
F.2
ACTUATOR LOCKNUT TOOL
1
KIT F OC2 DROPPER 27,2-80mm
X0940000 F.3
ACTUATOR ASSEMBLY
1
F3
F1
F2
Tool: For removing lock nut
KIT F
KIT E CODE COMPONENTS QUANTITY
KIT E OC2 DROPPER. 31.6mm
FOR ALL DROPS
X0900000
E.1
SEAL COLLAR RING
1
E.2
LOWER BUSHING
1
KIT E OC2 DROPPER 27.2-80mm
X0930000 E.3
GUIDES
2
E.4
UPPER BUSHING
1
E1
E2
E3
E4
KIT E
