Orbea ORCA AERO OMX User Manual

BLUE PAPER ORCA AERO · OMX 20222 | ORBEA ORBEA | 3TECHNICAL MANUAL
EN
INDEX
01 KEY TO SYMBOLS 4
02 ORBEA WARRANTY 6
03 MAINTENANCE 8
Maintenance schedule of the components 09
Replacement parts 11
After a crash or an impact 11
04 USE WARNINGS. ORCA AERO 12
Maximum tire width 12
Minimum seatpost insertion 12
Maximum number of headset spacers 12
Headset spacers above the stem 13
Intended use 13
05 ORCA AERO OMX 2022 14
Geometry and sizing 16
6GEJPKECNURGEKƂECVKQPU 
Assembly, use and spares 22
Headset 22
Axles and rear derailleur hanger 25
.QYGTHTCOGURCTGU 
Seatpost 29
Stem 32
Handlebar 40
Storage. OC Aero bottle and Toolbox 43
Frame protectors 46
Cable routing 47
Electronic groupsets cable routing 50
Powermeters 52
Cutting the fork steerer tube 53
06 DECLARATION OF CONFORMITY 54
07 ADDITIONAL INFORMATION 55

Orbea ORCA AERO OMX Specifications

General

Brand	Orbea
Model	ORCA AERO OMX
Category	Bicycle
Language	English
