Orbea ORCA AERO OMX User Manual

BLUE PAPER ORCA AERO · OMX 202216 | ORBEA ORBEA | 17TECHNICAL MANUAL
EN
GEOMETRY AND SIZING
ORCA AERO
SIZES 47 49 51 53 55 57 60
1 - Seat Tube (C-T) 459 474 499 524 544 564 
2 - Top Tube (EFF) 507.6  532.9 545.5 557.5 573.1 
3 - Head Tube 93.1  117.2 134.9 15.2 173.2 200.4
4 - Chainstay       
5 - BB Height 260 260 260 262 262 262 262
6 - BB Drop 76 76 76 74 74 74 74
7 - Wheelbase 966.2 971  976.1  996.9 
8 - Head Angle 71 71.5º 72.2º  73º 73.2º 73.2º
9 - Seat Angle 74.5º 74º 73.7º 73.5º 73.5º 73.2º 73.2º
10 - Standover 717  750.1 775 794  
11 - Reach 370 376   391  404
12 - Stack 496 505 523 542 562  606
13 - Fork Length 370 370 370 370 370 370 370
HEIGHT (CM) HEIGHT (IN) SIZE
155-160 61.1”-63.0” 47
160-166 63.0”-65.4” 49
167-172 65.7”-67.7” 51
173-179 qq 53
 qq 55
 73.2”-75.2” 57
192-207 qq 60
* *The measurements in the sizing table are orientative. The best way to know the correct frame size for you is to try a
bike at one of our authorized dealers.
