BLUE PAPER ORCA AERO · OMX 202218 | ORBEA ORBEA | 19TECHNICAL MANUAL
EN
TECHNICAL SPECIFICATIONS
ORCA AERO OMX
MATERIAL
Frame Orbea OMX carbon
Fork Orbea OMX carbon (steerer tube and blades)
INTENDED USE Road Aero. ASTM Condition 1
AVAILABLE SIZES 47, 49, 51, 53, 55, 57, 60
STEM
OC ICR01 R2 stem: Internal cabling in stem and headset
Compatible with standard stems with the use of the HS01 adapter
FORK RAKE
5K\GU4CMGOO
Sizes 53, 55, 57, 60: Rake 43 mm
MAXIMUM NUMBER OF HEADSET
SPACERS
40 mm
FORK STEERER TUBE
6CRGTGF
Integrated fork crown race
FORK LENGHT
(AXLE-TO-CROWN)
370 mm
HEADSET BEARINGS
7RRGTYKVJVQCFCRVGTHQTKPVGTPCNECDNKPI
Lower 1" 1/2
WHEEL SIZE 700C
MAXIMUM TYRE WIDTH
ETRTO: 30-622
Tyre maximum external diameter: 691 mm
Tyre maximum real external width: 32mm
Minimum tyre-frame/fork radial clearance: 4 mm
Minimum tyre-frame/fork radial clearance: 5 mm
BOTTOM BRACKET 24'55(+6$$'81
BOTTOM BRACKET SHELL WIDTH OO
BOTTOM BRACKET SHELL DIAMETER 46 mm
FRONT HUB STANDARD 12x100mm Speed Release (Thru-axle)
FRONT AXLE MEASUREMENTS 12x119mm
FRONT AXLE THREAD PITCH Double lead Speed Release 2P1.0
FRONT AXLE THREAD LENGHT 13mm
REAR HUB STANDARD 12x142mm Speed Release (Thru-axle)
REAR AXLE MEASUREMENTS 12x165mm
REAR AXLE THREAD PITCH Double lead Speed Release 2P1.0
REAR AXLE THREAD LENGHT 15mm
SEATPOST
%CTDQPCGTQ1TEC#GTQURGEKƂE
Sizes 47, 49, 51: 290 mm
Sizes 53, 55, 57, 60: 330 mm
SEATPOST CLAMP +PVGITCVGFYGFIG1TEC#GTQURGEKƂE
SEATPOST MINIMUM INSERTION
Seatpost 290 mm: 100 mm minimum insertion
Seatpost 330 mm: 100 mm minimum insertion
FRONT DERAILLEUR Down-Pull. Braze-On. Removable hanger
FRONT DERAILLEUR ANGLE 63º
MAXIMUM BIG CHAINRING SIZE (2X)
55T Sram 2x11 and Shimano 2x11-2x12
54T Sram 2x12
MINIMUM BIG CHAINRING SIZE (2X)
65TCOZCPF5JKOCPQZZ
46T Sram 2x12
MAXIMUM BIG OVAL
CHAINRING SIZE (2X)
56T
MAXIMUM SMALL OVAL
CHAINRING SIZE (2X)
42T
MINIMUM SMALL CHAINRING SIZE (2X) 34T
