Orbea ORCA AERO OMX User Manual

BLUE PAPER ORCA AERO · OMX 202220 | ORBEA ORBEA | 21TECHNICAL MANUAL
EN
MAXIMUM SMALL CHAINRING SIZE (2X) 42T
MAXIMUM ROUND
CHAINRING SIZE (1X)
53T
MAXIMUM OVAL CHAINRING SIZE (1X) 52T
TRIPLE CHAINRING COMPATIBLE NO
CHAINLINE
Depends on drivetrain used.
Consult drivetrain compatibility section.
MINIMUM Q-FACTOR 145.5 mm
MAXIMUM CRACKARM LENGTH 175 mm
REAR DERAILLEUR Standard derailleurs (no Direct Mount)
DRIVETRAIN COMPATIBILITY
(Disc brake groupsets only)
Shimano Road: 11S, 12S (Mechanical and Di2 11S and 12S -internal battery-)
Sram Road: 11S, 12S (Mechanical and Etap) 1x and 2x
Campagnolo 11S, 12S (Mechanical)
EPS not compatible
FRONT BRAKE Disc. Flat Mount*
FRONT ROTOR MÍNIMUM/MÁXIMUM
DIAMETER
140mm/160mm (turning the Flat Mount adapter)
REAR BRAKE Disc. Flat Mount*
REAR ROTOR MÍNIMUM/MÁXIMUM
DIAMETER
140mm/160mm (with 20mm adapter)
REAR CALIPER FLAT MOUNT BOLT
LENGHT
(CHAINSTAY HEIGHT=15mm)
5*+/#01OO
SRAM: 22 mm
CABLING
Rear derailleur: Internal through headset, downtube and chainstay. Full housing
Front derailleur: Internal through headset and downtube. Full housing
Front brake: Internal through headset and fork blade
Back brake: Internal through headset, downtube and chainstay.
BOTTLE HOLDER
2. All sizes.
Compatible with Orbea 500ml Aero bottle
DI2 AND EPS COMPATIBLE
Di2: Yes. BT-DN110 and BT-DN300 batteries
EPS: No
MUDGUARDS COMPATIBLE No
REAR RACK COMPATIBLE No
CHILD SEAT COMPATIBLE No
TRAILER COMPATIBLE No
POWERMETER COMPATIBILITY**
Shimano: Yes
Stages: Check with manufacturer. https://stagescycling.com/us/factory-install/
Rotor InSpider BCD 110 V3: ;GU9KVJ$$CFCRVGTOOURCEGT
4iiii Precision: Check with manufacturer.
https://4iiii.com/c/pages/how-does-a-factory-install-work/
4iiii Podiiiium: Yes
QUARQ: Yes
Powerbox: Yes
STORAGE
Toolbox underneath the downtube
Capacity for: 1 tube, 2 CO2 cartridges, 1 CO2 adapter
UCI LEGAL CERTIFIED Yes
MAXIMUM STRUCTURAL WEIGHT LIMIT
(RIDER+GEAR+LUGGAGE)
Consult the Orbea Products Structural Weight Limit document on Orbea´s website
0QVCNNECNKRGTUCPFTQVQTUKPVJGOCTMGVCTGEQORCVKDNGYKVJCNNHTCOGU#NNEQORQPGVUURGEKƂECVGFHTQO1TDGCJCXGDGGPVGUVGF
For aftermarket options, check componentes dimensions and tolerances befores purchasing.
** For other powermeters different from the ones listed, consult dimensions and options with manufacturer.
TECHNICAL SPECIFICATIONS
ORCA AERO OMX
