TECHNICAL MANUAL BLUE PAPER ORCA · OMR 20212 | ORBEA ORBEA | 3
EN
INDEX
01 INTRODUCTION 4
Key to symbols
02 ORBEA WARRANTY 6
03 MAINTENANCE 8
Maintenance schedule
Spare parts
After a crash or an impact
04 WARNINGS OF USE 12
Maximum tyre width
Minimum seatpost insertion
Maximum number of headset spacers
Headset spacers on above the stem
Intended use
05 ORCA OMR 2021 14
Geometry and sizing
6GEJPKECNURGEKƂECVKQPU
Assembly and spare parts
Headset
Axles and rear derailleur
Frame hardware
Cabling
Stems
Cutting the fork steerer tube
06 HANDLEBARS 42
07 POWERBOX POWERMETER 43
08 DECLARATION OF CONFORMITY 44
09 ADDITIONAL INFORMATION 45
EN P.03 | ES P.46

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Orbea ORCA M20iTEAM and is the answer not in the manual?

Orbea ORCA M20iTEAM Specifications

General IconGeneral
BrakesShimano Ultegra R8170 Hydraulic Disc
ShiftersShimano Ultegra Di2 R8170
Rear DerailleurShimano Ultegra Di2 R8150
Front DerailleurShimano Ultegra Di2 R8150
ChainShimano M8100
Weight7.8 kg
FrameOrbea Orca OMR
ForkOrbea Orca OMR
GroupsetShimano Ultegra Di2
TiresVittoria Corsa
HandlebarOrbea OC Road
SeatpostOC2 Carbon 27.2mm
CranksetShimano Ultegra R8100 52x36t
HeadsetFSA
StemOrbea OC Road
CassetteShimano Ultegra R8100 11-30t
SaddleFizik
