01 INTRODUCTION
The symbols DANGER and WARNING inform about a dan-
gerous situation that, if not avoided, may cause an acci-
dent. An accident while riding a bicycle always poses risk
of serious injury or even death. In this manual, the risk of
death may therefore not always be mentioned when these
symbols appear, since the risk is explained here.
This technical manual contains important information about your bicycle, its
use, maintenance and replacement parts. Please read it carefully.
This document is a supplement to the General User’s Manual for Orbea bicycles
and components, which describes in a more detailed manner their appropriate
use and the adjustment of the general components of the bicycles for safe
riding and operation. You can see and download the User’s Manual and the rest
of the technical manuals for Orbea products from our website:
www.orbea.com/us-en/soporte/manuales
You can consult the information on the use, maintenance and characteristics
of the components of other manufacturers that are assembled on our bicycles,
such as wheels, handlebars, pedaling assistance systems, suspension forks,
etc, on the manufacturer’s website or through their dealer in your country.
KEY TO SYMBOLS
Throughout this technical manual, various symbols are used that indicate in-
structions and warnings for use, maintenance and assembly. Pay attention to
these symbols to avoid hazardous situations and ensure the correct use and
assembly of all components.
The meaning of these symbols is explained below. In this manual, the symbol
may appear accompanied only by the relevant instruction for the component
described. Read the following information carefully in order to understand their
meanings.
66
10 N.m
SAFETY INSTRUCTIONS TOOLS AND TIGHTENING TORQUES
DANGER: Immediately hazardous situation.
If not avoided, serious injury or even death
will occur.
WARNING: Potentially hazardous situation.
If not avoided, serious injury or even death
may occur.
CAUTION: Potentially hazardous situation.
If notavoided, minor or moderate injury
may occur.
Not related to injury. Property situation
hazard.
SPANNER
ALLEN KEY
TORX KEY
PHILLIPS
SCREWDRIVER
The key number is indicated
inside the symbol.
ASSEMBLY COMPOUNDS
GREASE
FIBER CARBON GRIP
OIL: Light lubrication of elements like chains
and cables.
GREASE: High quality assembly grease to
avoid creaking and seizing.
CARBON PASTE: %CTDQPƂDGTCUUGODN[
compound to increase friction between
ECTDQPƂDGTEQORQPGPVU
LOCTITE SERIES 600: Fixing cylindrical
surfaces.
LOCTITE SERIES 200: Threadlock. Medium
resistance.
LOCTITE SERIES 400: Instant adhesive.
TIGHTENING TORQUES: The corresponding tightening
torque (in Newtons/meter) is indicated beneath the sym-
bol of the tool to use for the element described.
