DIAGRAM DESCRIPTION PART
NUMBER OF PART NUMBER
1 (A) Front Cover Comfort View I CCV - 1001
1 (B) Front Cover Comfort View II CCV - 2001
1 (C) Front Cover Comfort View III CCV - 3001
1 (D) Front Cover Calorama I CCV - 4001
1 (E) Front Cover Calorama II CCV - 5001
1 (F) Front Cover Calorama III CCV - 6001
2 Front Cover Fasteners Assembly CCV - 5002
3 Main Burner support gasket CCV - 5003
4 (A) Main Burner Injector CCV I N. G. (ø1.22mm) CCV -1004N
4 (B) Main Burner Injector CCV I L P. (ø0.82mm) CCV -1004P
4 (C) Main Burner Injector CCV II N. G. (ø1.80mm) CCV - 2004N
4 (D) Main Burner Injector CCV II L P. (ø1.15mm) CCV - 2004P
4 (E) Main Burner Injector CCV III N. G. (ø2.10mm) CCV - 3004N
4 (F) Main Burner Injector CCV III L P. (ø1.35mm) CCV - 3004P
5 Main Burner Injector Adaptor CCV - 5005
6 (A) Pilot Injector CCV N. G. (ø0.25mm 2x) CCV –5006N
6 (B) Pilot Injector CCV L. P. (0.20mm) CCV – 5006P
7 Electrode Ceramic CCV - 5007
8 Electrode Ceramic Fixing Nut CCV - 5008
9 Thermocouple Fixing Nut CCV - 5009
10 Thermocouple CCV - 5010
11 Main Gas Valve N. G. CCV - 5011N
11 Main Gas Valve L. P. CCV – 5011P
12 (A) Minimum Rate Screw, CCV I – N. G. (ø0.90mm) CCV – 1012N
12 (B) Minimum Rate Screw, CCV I – L. P. (ø0.70mm) CCV – 1012P
12 (C) Minimum Rate Screw, CCV II – N. G. (ø1.30mm) CCV – 2012N
12 (D) Minimum Rate Screw, CCV II – L. P (ø0.90mm) CCV – 2012P
12 (E) Minimum Rate Screw, CCV III – N. G. (ø1.70mm) CCV – 3012N
12 (F) Minimum Rate Screw, CCV III – L. P. (ø1.10mm) CCV – 3012P
13 Piezoelectric Igniter Assembly CCV - 5013
14 Knob Set (Piezo & Gas Valve) CCV - 5014
15 (A) Vent Kit, CCV I and CCV II CCV - 5015A
15 (B) Vent Kit, CCV III CCV - 5015B
