Orbis COMFORTVIEW - Heater Specifications; General Installation Warning; CCV Series Heater Specifications

5
CALORAMA/COMFORT VIEW (CCV) SERIES HEATER SPECIFICATIONS
Model
Maximum input BTU/h (KW) 
Minimum input BTU/h (KW) 
NATURAL GAS
Manifold Gas Pressure:
Minimum Gas Supply Pressure 
Maximum Gas Supply Pressure 
PROPANE/LP GAS *
Manifold Gas Pressure: 
Minimum Gas Supply Pressure
Maximum Gas Supply Pressure
Gas Inlet Connection 
Minimum Wall Thickness
Maximum Wall Thickness 
Vent Opening Diameter in Wall
Height of Unit  
Width of Unit 
Depth of Unit (including wall
mounting Plate)
8 000 (2,32)  15 000 (4,40)  20 000 (5,86)
4 100 (1,20)  6 900 (2,00)  9 500 (2,78)
4" (102 mm) wc  4" (102 mm) wc 4" (1 02 mm) wc
5" (127 mm) wc 5" (127 mm) wc 5" (1 27 mm) wc
7" (178 mm) wc 7" (178 mm) wc 7" (1 78 mm) wc
10" (254 mm) wc  10" (254 mm) wc 10" (254 mm) wc
11" (279 mm) wc  11" (279 mm) wc 11" (279 mm) wc
13 " (330 mm) wc 13" (330 mm) wc 13" (33 0 mm) wc
3/8" NPT  3/8" NPT  3/8" NPT
2" (51 mm)  2" (51 mm)  2" (51 mm)
12" (305 mm)  12" (305 mm)  12" ( 305 mm)
8,31" (211 mm)  8,31" (211 mm)  8,31 " (211 mm)
23,23" (590 mm) 23,23" (590 mm) 23,23" (590 mm)
13,78" (350 mm) 19,69" (500 mm) 27,56 " (700 mm)
7,64" (194 mm)  7,87" (200 mm)  8,27" (210 mm)
Note: Minimum gas inlet gas pressure is for purpose of input adjustment.
* Exterior Regulator pressure MUST NOT EXCEED 13 IN. W.C.
CCVI
Calorama/Comfort 
View I
CCVII
Calorama/Comfort 
View II
CCVIII
Calorama/Comfort 
View III
WARNING: IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION,
SERVICE OR MAINTENANCE CAN CAUSE INJURY OR PROPERTY
DAMAGE: REFER TO THIS MANUAL. FOR ASSISTANCE OR
ADDITIONAL INFORMATION, CONSULT A QUALIFIED INSTALLER,
SERVICE AGENCY OR YOUR GAS SUPPLIER.
