On transfer completion the option to upload to other equipment appears …
The ERASE option will independently remove the programming.
CONFIGURATION
This permits manual adjustment of the remote control parameters, such as date,
time, language, display contrast and full or partial memory erase.
By using the Clear Memory menu, all saved equipment can be deleted or the
memory formatted. (Formatting takes approximately one minute and will delete)
LOCATION BY CITIES
The position can be located with the Cities by country menu, with which the
geographical position is established by choosing the nearest city from a list of
the largest cities in the country .
City transfer: select the city and choose the SEND YES option with OK and
point the remote control towards the device. The device will show INFRARED
PRESS MENU and pressing MENU will commence the data transfer.
When the transfer is completed, the option to upload to other equipment is
displayed …
TECHNICAL SPECIFICATIONS
Power supply 2 alkaline batteries LR03/AAA, 1.5 V
Battery life On mode: approx. 24 hours
Off mode: approx. 1 year
Display Backlight LCD
Communications Infrared port
Infrared range maximum 1 metre. Angle: 20º.
Operating temperature -10ºC to +45ºC
DIMENSIONS
A016.61.55196
ORBIS TECNOLOGÍA ELÉCTRICA S.A.
Lérida, 61 E-28020 MADRID
Tel.: + 34 91 567 22 77 Fax + 34 91 571 40 06
E-mail: info@orbis.es
http://www.orbis.es
52
100
24
SENDING
Zone...
SENDING
Sent...Ok
¿Other one?
NO YES
MENU
Devices
Location
Configuration
CONFIG
Contrast
Language
Clear Memory
Date and Time
CITIES BY COUNTRY
ITALIA
PORTUGAL
ESPAÑA
LOCATIONS
GPS capture
Send GPS coordinate
Cities by country
ESPAÑA
Andalucía
Aragón
Astrurias
Cantabria
Aragón
Huesca
Teruel
Zaragoza
Aragón
Zaragoza
¿Send?
NO YES
SENDING
Zone...
SENDING
Sent...Ok
¿Other one?
NO YES
