Orbit X304 - Assembly Step 8; Assembly Step 8: Explosion Drawing

Assembly step（8）explosion drawing
21
10
11
59
57
69
70
71
No. Descripon Note Qty.
10 lock nut M10 2
11 washer Φ10 1
57 pulley Φ95 1
59 hexagon bolt M10*45 1
69 pulley frame 1
70 wire Φ5*1705mm 1
71 5 secon chain + snap 1
