Orbit X304 - Assembly Step 8: Assembly Instructions

22
Assembly step（8）drawing
Assembly step（8）assembly instrucon
1
Fix pulley-57 fastening on ”-“ shape pulley frame-63 using M10x45 hexagon bolt-59, Φ10
washer-11 and M10 lock nut-10
2
As the shown in the figure connect wire-70, pulley frame-69 and 5 secon chain + snap
hook-71 on the main frame
