24
the orientation of the nozzles using the markers to make the pool cleaner describe a trajectory
following a slight curve.
a. Adjustment of nozzles and trajectories
generality：Nozzle angle markers from 0 ° to 40 °
Set the nozzles to 0°，the unit operates in a straight line.
Position the nozzles at 0° to 40° to obtain an increasingly large curve.
b. Example of nozzle positions
Example 1: Default setting: 0°--20°, for most pools
