I.2 Presentation
The ORCA 300 robot is a very efficient and energy efficient pool cleaning robot. Thanks to its
elaborate control programs, it can automatically clean the walls, bottom and water line of the pool.
At the same time, it filters the pool water and removes suspended particles without the need to
replace the pool water. It is totally environmentally friendly.
To work safely, the robot operates on 28 Volts direct current.
I.3 Packaging
No. Designation Réf. Qté comments
1 Device 107104 1 In box
2 Power supply unit 1 In box
3
Operating instruction
and safety wire
1 In box
1.4 Technical informations
Input Voltage : 220 VAC (230 VAC Frequency : 50Hz/60Hz
Output Voltage : DC 28V Output power : 150W
Cleaning cycle : 1H/ 2H/3H Filtering capacity: appr. 15 cbm/h
Filter density: 10 micorns Moving speed : envr. 10m/min
depth max : 2.5m Max Cleaning surface : 130 m²
Working temperature : 0° +40°
IP grade: Cleaner IPX8;
Power supply unit: IPX5
