Oreck AIR REFRESH WK15500B - Operation: Control Panel and LCD Display

10
WARNING IMPORTANT: THE CONTROL PANEL IS TOUCH SENSITIVE, LIGHTLY PRESS THE CONTROLS. WHEN THE MACHINE IS ACTIVATED, THE DIGITAL
HUMIDITY READING OF THE ROOM AND THE SPINNING IMAGE OF THE FAN WILL CONSTANTLY BE DISPLAYED. HUMIDIFICATION STARTS AFTER THE INITIAL WATER
CYCLE. MIST MAY NOT BE VISIBLE IN ALL CONDITIONS.
Operation — How the Control Panel and LCD Display Screen Work
A
On/Off
B
Speed
C
Timer
D
Sleep
E
Humidity
F
Reset Filter
Control Panel
LCD Display
Screen
Fig. 6
Fig. 1 Fig. 5 Fig. 4 Fig. 3
Fig. 7
Fig. 2
