Inside the DTX 1300/1400 Hose Handle
If the yellow plastic ring is not installed
then the metal contact ring will slide out
of position and the power will loose
contact.
EBK340 - DTX1400 Power Nozzle Service
10/08/2007
Remove 6 screws from base.
All screws are the same size.
Turn the nozzle over and tilt the
top cover from the back.
Increase Quality Through Interaction with the Field
28
