Oreck QS110 SERIES - Product Assembly Guide; Model QS110 Series Components

3
Assembly
Model QS110 Series
1. Main housing
2. Hand held vacuum
3. Power head
4. Dirt Cup
5. ON/OFF handle switch
6. Handle control button
7. Release button for hand held vacuum
8. Charging socket
9. Hand held vacuum ON/OFF switch
10. Charging lamp
11. Release button for dirt cup
12. Dust filter (included in the hand held unit)
13. Adapter (power supply/charger)
2
3
4
5
6
7
8
9
10
11
12
13
1
