Operating Instructions
Cleaning the Dust Filter
Fig. 9 Empty dirt cup.
Fig. 10 Remove the filter frame from
the dust filter.
Fig. 11 Wash the filter in warm soapy
water, using a soft brush if
necessary. Dry the filter
completely before replacing it
into the filter frame and dirt
cup.
Replace the dust filter on the
filter frame and insert into dirt
cup.
Replace dirt cup onto handheld
vacuum.
Power Brush
Important: Disconnect cleaner from
electrical outlet.
Fig. 12 To maintain cleaning
effectiveness, regularly remove
hair, lint, strings, threads, etc.
from the brush roll with a knife or
scissors.
Storing the Vacuum
Fig. 13 Press the handle control button
and bend the handle down for
easy storage.
9
11
13
6
