Oricom UHF2180 instructions
Oricom UHF2180 instructions
Antenna
Speaker MIC (Microphone)
LCD Screen
- Displays the current channel
selection and other radio
symbols.
PTT (PUSH to TALK)
button
- Press and hold to
transmit.
UP/DOWN Buttons
- Press to change
channels, volume, and
to select settings during
programming.
MENU Button
- Press to change
To switch between
Modes
CALL button
- Press to send Ringing
tone to other radio units.
PWR/VOL Switch
- Rotate clockwise/
counter clockwise to
turn the unit ON or OFF.
Ear/Mic/Charge
jack
LCD Screen
Channel Number. Changes from 1 to 80 as
selected by the user.
CTCSS Code. Changes from 1 to 38 as selected by the user.
Displays the Battery change level. When the bars are reduced, the
battery needs to recharge.
Displayed when transmitting a signal.
Displayed when receiving a signal.
Displayed when the Dual Watch function is turned ON.
Displayed when the Digital Code System is turned On.
Displayed when the VOX feature is enabled.
Displayed when the radio is doing scan.
RPT
Displayed when the repeater function is activated.
Displayed when the call signal is ON.
Displayed when the vibrator function is activated.
Displayed when the Key Lock feature is activated.

Oricom UHF2180 Specifications

General

Brand	Oricom
Model	UHF2180
Category	Two-Way Radio
Language	English
