10
X - Y / -
ARC
/+
POWER
RESET
HEAT
AUTO
Figure 5-2
Table 5-1
Key
Function Description
POWER
This key is power, when it was pressed for
about 0.5 second; the instrument would turn on
or turned off.
HEAT
P r ess to operate the reinforcement heater.
The red lamp is lit during operation. And
if
the
cover is covered, the heater will work also . The
heating time can be set in the menu, the
operation refer to APPENDIX B . I f the key is
pressed in the heating procedure, the heater
will stop heating.
RESET
All operations except heating would be
canceled,
if
this key was pressed, and all the
m otional p arts will be move to default position ,
and the instrument is ready for next fusion.
