If the electrode's deviation is within 1 0, no adjustment is needed. The
electrodes location adjustment requires high skill. It should be done
by a technician. If the value of "GAP" is between 15 and 25, the arc
power is suitable for fiber splicing . I f the value of “ GAP ” is less than
this range , please increase " Prefuse Power " and " Fuse Power " ,
contrarily , decrease " Prefuse Power " and " Fuse Power " . Press
the key to return to the former operation after the test is done .
Before the Arc Power test, the electrodes should be cleaned. The test
is effective only after the arc becomes stable.
A
A
A
A .3
.3
.3
.3 Overlap
Overlap
Overlap
Overlap
Test
Test
Test
Test
Choose the " Overlap Test " item in test menu and press key to
confirm. Now the screen displays as Figure A-3.
T Overlap Test
2010
-
02
-
26 9
:
35 24
℃
43
%
RH
X
Y
Figure A-3
a. Send the two end profile s of fibers to the center of the screen
automatically, and accomplish gap setting.
b. The left fiber exits from the screen, but the right fiber goes
To Next Page
