Origen ae M10 - Opening the Case; Optical Disk Drive Installation

Opening the case
Remove the 4 fixing screws as indicated1. Carefully raise the panel as shown 2.
1
2
Optical disc drive installation
Loosen(no need to remove) the 4 fixing screws. Keyhole shaped holes
allow the ODD bracket to slide up and be lifted out over the screw
heads. install the ODD as shown.
ODD
bracket
12.7mm slot
load ODD
5
