Explorer Collection™ Manual
Twist Clockwise
to Lock
1. Fit into Ring
2. Twist into Ring
Fit the speaker into the bayonet ring, and twist it clockwise into place. When the
lines on the speaker lines up with the lines on the bayonet ring, that means the
speaker is tightly in place. Be sure that the lines line up, otherwise there’s a risk
that the speaker will fall out of the ceiling.
6. Installing the Speaker
11
MARINE GRADE SILICONE
Inner Border “A”
Outer Border “B”
Silicone Sealant: In all applications where moisture is a concern, care should be
taken to completely seal the speaker to the bayonet ring (Inner Border ‘A’) and also
seal the bayonet ring to the installation surface (Outer Border ‘B’). It is strongly
recommended that a liberal bead of marine grade silicone be applied in these
two areas. This will improve weather resistance and also assure that mechanical
vibrations, like those common in watercra, will not dislodge the loudspeaker.
