Origin Effects CALI76 User Manual

10
Origin Eects Cali76 FET Compressor
Measurement Unboxed Boxed
Weight 553g (19.5oz) 661g (23.3oz)
Length 124mm (4.8”) 135mm (5.3”)
Depth 64mm (2.5”) 90mm (3.5”)
Height 58mm (2.3”) 85mm (3.3”)
Measurement Value
Input impedance 1M Ω
Output impedance 1k Ω
Current draw 200mA
Power supply requirements 9VDC 2.1mm centre negative connector
Pin Description
Tip Signal
Sleeve Ground
Appendix A: Physical Specification
Appendix B: Performance Specification
Instrument & Amplifier 1/4” TS Sockets:
Appendix C: Connector Pin Out

Origin Effects CALI76 Specifications

General

Type	Compressor
Technology	Analog
Output Impedance	1 kΩ
Bypass	True Bypass
Power Supply	9V DC
Controls	Input, Output, Ratio, Attack, Release
Attack	Variable
Release	Variable
Circuit Type	Class-A, discrete transistor
Input Impedance	1 MΩ
Weight	620 g (1.37 lbs)
