Figure 1. The SkyView Pro EQ Mount.
2
Declination lock lever
(opposite side)
Right ascension lock lever
(opposite side)
Declination slow-motion
control-knob
Safety thumbscrew
Mounting plate securing knob
Counterweight shaft
Counterweights
Counterweight lock knobs
Tripod leg
Right ascension slow-motion
control knob
Latitude scale
Latitude adjustment L-bolts
Center support shaft
Tripod support tray
Tube ring mounting plate
Leg lock knobs
