Orion Welders LZR series User Manual

21
Chapter 4: Technical Data
4.1: LASER SPECIFICATIONS
SPECIFICATIONS DESCRIPTION
Electric Input VAC 110V or 230V
Electric Power Phase Single Phase
Electric Frequency Hz 50-60
Average Energy Consumption KW 1.7
Laser Crystal Type Nd:YAG
Wavelength nm 1,064
Weld Energy joule 0.1-60 or 0.1-100
Weld Length msec 0.5-20
Repetition Frequency Hz 0.5-30
Average Power W 75
Max Peak Power KW 7
Duty Cycle 80%
Weld Spot Sizes mm 0.2-2.0
Maximum Argon Gas Pressure bar 1.5
Cooling Type Liquid
Fuse 12 AT
Weight lbs (kg) 100 (45)
Sizes in (cm) 20x35x22 (50x90x56)
4.2: OTHER DATA
SPECIFICATIONS DESCRIPTION
Work Environment Temperature °C 17-35
Maximum Humidity during Operation % 65
Noise Level dB(A) <70
Recommended Argon Purity % 99.8-99.996
Shield Gas (Argon) Consumption l/min 2-4 con 1.5 bar

Orion Welders LZR series Specifications

General

Brand	Orion Welders
Model	LZR series
Category	Welding System
Language	English
