7
7. Lightly re-tighten the three recessed locking screws with a 2.5mm Allen
key.
Be sure to turn the illuminator off when nished using the polar scope! Do this by
rotating the battery cap counterclockwise until the red LED turns off. (Then rotate
the small brightness dial in the same direction all the way.)
Powering the Illuminator
The Illuminated Polar Scope comes with a CR2032 lithium button cell battery,
which powers the red LED that lights up the reticle. To install the battery, unscrew
the battery cover (Figure 2) and insert the battery with the positive (+) side facing
up. Then screw the battery cover back on.
The illuminator does not have an ON/OFF switch. To turn it on, you rotate the bat-
tery cap clockwise until the LED light comes on. You can adjust the brightness of
the illumination with the brightness dial. To turn the illuminator off, rotate the battery
cap counterclockwise until the LED light goes off.
