Orion Cobalt CTW101 User Manual

WARNING
Continuous exposure to sound pressure levels over 100dB may
cause permanent hearing loss. High powered sound systems may
produce sound pressure levels well over 135dB.
Need we say more! Use common sense.
SPECIFICATIONS
3
Specifications
CTW101
RMS Power Watts 50
MAX Music Power Watts 200
Nom Impedance (Ohm) 4
Voice Coil 1”
Magnet Structure 20 Oz
Frequency Response 2kHz - 20kHz
SPL(dB) 99
Overall Depth 43.8mm / 1.724”
Mounting Depth 38.4mm / 1.512”
Overall Diameter 95.7mm / 3.768”
Mounting Diameter 71.3mm / 2.807
Recommended Capacitor 3.3 UF 100V
Person:
Company:
Project:
File: CTW101-TS
参参数数.lib
Mar 13, 2023
Mon 8:56 am
4.6.0.371
5月月/30/2007
Notes Map
1: CTW101-SPL
200 Hz 500 1K 2K 5K 10K 20K
dBSPL
30
40
50
60
70
80
90
100
110
SPL vs Freq

Orion Cobalt CTW101 Specifications

General

Brand	Orion
Model	Cobalt CTW101
Category	Car Stereo System
Language	English
