WIRING CONFIGURATION
2 ohm
+ +
- -
+
-
2 ohm
Series - One Speakers (Dual 2 ohm voice coils)
One dual 2 ohm voice coil woofer with voice coils in connected in series
results in a 4 ohm load to the amplifier.
2 ohm
+ +
- -
+
-
2 ohm
Parallel - One Speakers (Dual 2 ohm voice coils)
One dual 2 ohm voice coil woofer with voice coils in parallel
results in a 1 ohm load to the amplifier.
