Orion HCCA BLACK COIL Series User Manual

6
WIRING CONFIGURATION
RE-CONE KIT
A re-cone kit is available for these speakers and can be obtained from your dealer.
The part number for each model is listed below.
Model/Part#
Description
HCCA102RK
ORION HCCA 10” 2 OHM Re-Cone Kit
HCCA104RK
ORION HCCA 10” 4 OHM Re-Cone kit
HCCA122RK
ORION HCCA 12” 2 OHM Re-Cone Kit
HCCA124RK
ORION HCCA 12” 4 OHM Re-Cone Kit
HCCA152RK
ORION HCCA 15” 2 OHM Re-Cone Kit
HCCA154RK
ORION HCCA 15” 4 OHM Re-cone Kit
WIRING CONFIGURATIONS
The following illustrations provide guidelines on properly connecting your HCCA
Orion woofer to an amplier for maximum power and performance using common
parallel, and series/parallel wiring congurations.
Recommended Amplier Power
1 woofer
1,200 to 4,000 Watts
2 woofer
2,400 to 8,000 Watts
3 woofer
3,600 to 12,000 Watts
4 woofer
4,800 to 16,000 Watts
