1 connection diagram
Connect the other end of video/power
cable (BNC connector only) to BNC video
input on DVR rear panel.
1
6 7 8 9
2
Connect camera to
video/power cable.
Connect monitor
to DVR VGA video
output.
Connect mouse to
DVR USB input.
Connect router to DVR LAN
port using ethernet cable.
ACCESSORIES
SPEAKERS
MEMORY
DEVICE
PTZ CAMERA
3 4
Connect camera
power supply to
power splitter and
power point.
Connect DVR
power supply to
DVR power input
and power point.
5
Connect the other end of video/
power cable (DC connector only)
to power splitter.
Repeat steps 1 - 3 with
all 4 cameras
