2
Figure 1. The SkyView Pro GoTo System (not all parts on parts list are shown)
Motor control box bracket
R.A. GoTo motor cover
Dec. GoTo motor cover
Dec. GoTo motor
Motor control box
GoTo hand controller
bracket
GoTo hand
controller
Motor cables
GoTo hand controller cable
R.A. GoTo motor
Brass gears
