Orion vortex R10 User Manual

Technical Specifications
Model 65101 65102
Type Sensor / Sensorless Sensor / Sensorless
Const. / peak Amp 120A / 760A 160A / 760A
Resistance 0.0003 ohm 0.0003 ohm
Function
forward/brake – forward/brake reverse
forward/brake – forward/brake
reverse
forward/reverse (for rock crawler) forward/reverse (for rock crawler)
Car type
1/12 on-road, 1/10 on-road and
off-road, Rock Crawler
1/12 on-road, 1/10 on-road and
off-road, Rock Crawler
Motor type
1S up to 3.5T 2S up to 2.5T
2S up to 4.5T 3S up to 5.5T
Up to 12000KV Up to 16000KV
Battery type
4-6 cells NiMH - NiCd 5-9 cells NiMH - NiCd
1-2 cells LiPo - LiFe 2-3 cells LiPo - LiFe
BEC 6V/2A, DC/DC Booster 5.75V/3A, Linear mode
Size 41.5x30.5x16.5mm w/o fan 41.5x30.5x20.2 mm w/o fan
Weight 40g 44g
Model 65105
Type Sensor / Sensorless
Const. / peak Amp 180A/950A
Resistance 0.0002 ohm
Function
forward/brake – forward/brake reverse
forward/reverse (for rock crawler)
Car type
1/8 off-road buggy, truggy and mon-
ster trucks, 1/8 on-road
Motor type
4S LiPo up to 3000KV
6S LiPo up to 2400KV
Battery type
2-6 cells LiPo/LiFe or 6-18 cells NiMH/
NiCd
BEC 5.75V/3A
Size 56x46.5x35mm
Weight 105g w/o wires
Model 65101 65102
Type Sensor / Sensorless Sensor / Sensorless
Const. / peak Amp 120A / 760A 160A / 760A
Resistance 0.0003 ohm 0.0003 ohm
Function
forward/brake – forward/brake reverse
forward/brake – forward/brake
reverse
forward/reverse (for rock crawler) forward/reverse (for rock crawler)
Car type
1/12 on-road, 1/10 on-road and
off-road, Rock Crawler
1/12 on-road, 1/10 on-road and
off-road, Rock Crawler
Motor type
1S up to 3.5T 2S up to 2.5T
2S up to 4.5T 3S up to 5.5T
Up to 12000KV Up to 16000KV
Battery type
4-6 cells NiMH - NiCd 5-9 cells NiMH - NiCd
1-2 cells LiPo - LiFe 2-3 cells LiPo - LiFe
BEC 6V/2A, DC/DC Booster 5.75V/3A, Linear mode
Size 41.5x30.5x16.5mm w/o fan 41.5x30.5x20.2 mm w/o fan
Weight 40g 44g
Model 65105
Type Sensor / Sensorless
Const. / peak Amp 180A/950A
Resistance 0.0002 ohm
Function
forward/brake – forward/brake reverse
forward/reverse (for rock crawler)
Car type
1/8 off-road buggy, truggy and mon-
ster trucks, 1/8 on-road
Motor type
4S LiPo up to 3000KV
6S LiPo up to 2400KV
Battery type
2-6 cells LiPo/LiFe or 6-18 cells NiMH/
NiCd
BEC 5.75V/3A
Size 56x46.5x35mm
Weight 105g w/o wires
Model 65109
Type Sensor / Sensorless
Const. / peak Amp 90A / 420A
Resistance 0.00055 ohm
Function
forward/brake – forward/brake reverse
forward/reverse (for rock crawler)
Car type
1/12 on-road, 1/10 on-road and
off-road, Short Course, Rock Crawler
Motor type
2S up to 5.5T
3S up to 10.5T
Up to 6000KV
Battery type
5-9 cells NiMH - NiCd
2-3 cells LiPo - LiFe
BEC 5.75V@3A, Linear mode
Size 41.5x30.5x20.2mm w/o fan
Weight 43g
