Orion vortex R10 User Manual

Model 65103 / 65108 65104 / 65107
Type
65103 Sensorless 65104 Sensorless
65108 Sensor / Sensorless 65107 Sensor / Sensorless
Const. / peak Amp 100A / 520A 130A / 760A
Resistance 0.0007 ohm 0.0004 ohm
Function
forward/brake – forward/brake reverse forward/brake – forward/brake reverse
forward/reverse (for rock crawler) forward/reverse (for rock crawler)
Car type 1/10 Truggy / Buggy / Monster 1/8 Truggy / Buggy
Motor type
2S Lipo – up to 6000KV 2S Lipo up to 6000KV
3S Lipo up to 4000KV 3S Lipo up to 4000KV
4S Lipo up to 3000KV
Battery type
6-9 cells NiMH - NiCd 6-12 cells NiMH - NiCd
2-3 cells LiPo - LiFe 2-4 cells LiPo - LiFe
BEC 6V/3A 6V/3A
Size 53.5x36x36mm 53.5x36x36mm
Weight 74g 79g
Model 65106/65110
Type Sensorless
Const. / peak Amp 45A/290A
Resistance 0.0012 ohm
Function forward/brake – forward/brake reverse
Car type 1/10 on-road and off-road
Motor type
2S Lipo – up to 6000KV On-Road /
4000KV Off-Road
3S Lipo up to 4000KV On-Road /
2500KV Off-Road
Battery type
2-3 cells LiPo/LiFe or
4-9 cells NiMH/NiCd
BEC 6V/3A
Size 31.5x27.5x33mm
Weight 74g w/wires
Model 65103 / 65108 65104 / 65107
Type
65103 Sensorless 65104 Sensorless
65108 Sensor / Sensorless 65107 Sensor / Sensorless
Const. / peak Amp 100A / 520A 130A / 760A
Resistance 0.0007 ohm 0.0004 ohm
Function
forward/brake – forward/brake reverse forward/brake – forward/brake reverse
forward/reverse (for rock crawler) forward/reverse (for rock crawler)
Car type 1/10 Truggy / Buggy / Monster 1/8 Truggy / Buggy
Motor type
2S Lipo – up to 6000KV 2S Lipo up to 6000KV
3S Lipo up to 4000KV 3S Lipo up to 4000KV
4S Lipo up to 3000KV
Battery type
6-9 cells NiMH - NiCd 6-12 cells NiMH - NiCd
2-3 cells LiPo - LiFe 2-4 cells LiPo - LiFe
BEC 6V/3A 6V/3A
Size 53.5x36x36mm 53.5x36x36mm
Weight 74g 79g
Model 65106/65110
Type Sensorless
Const. / peak Amp 45A/290A
Resistance 0.0012 ohm
Function forward/brake – forward/brake reverse
Car type 1/10 on-road and off-road
Motor type
2S Lipo – up to 6000KV On-Road /
4000KV Off-Road
3S Lipo up to 4000KV On-Road /
2500KV Off-Road
Battery type
2-3 cells LiPo/LiFe or
4-9 cells NiMH/NiCd
BEC 6V/3A
Size 31.5x27.5x33mm
Weight 74g w/wires
Model 65109
Type Sensor / Sensorless
Const. / peak Amp 90A / 420A
Resistance 0.00055 ohm
Function
forward/brake – forward/brake reverse
forward/reverse (for rock crawler)
Car type
1/12 on-road, 1/10 on-road and
off-road, Short Course, Rock Crawler
Motor type
2S up to 5.5T
3S up to 10.5T
Up to 6000KV
Battery type
5-9 cells NiMH - NiCd
2-3 cells LiPo - LiFe
BEC 5.75V@3A, Linear mode
Size 41.5x30.5x20.2mm w/o fan
Weight 43g
Model 65111
Type Sensorless
Const. / peak Amp 60A/290A
Resistance 0.0012 ohm
Function forward/brake – forward/brake reverse
Car type 1/10 on-road and off-road
Motor type
2S Lipo – up to 6000KV On-Road /
4000KV Off-Road
3S Lipo up to 4000KV On-Road /
2500KV Off-Road
Battery type
2-3 cells LiPo/LiFe or
4-9 cells NiMH/NiCd
BEC 6V/3A
Size 31.5x27.5x33mm
Weight 74g w/wires
