Programmable
Items
Programmable Value
1 2 3 4 5 6 7 8 9
Basic Items
1. Running Mode Forward
with
Brake
Forward/
Reverse
with
Brake
Foward/
Reverse
(For Rock
Crawler)
Zero Tim-
ing
Forward
with
Brake
Zero
Timing
Forward/
Reverse
with
Brake
Zero
Timing
Forward/
Reverse
(For Rock
Crawler)
2. Drag Brake Force
0% 5% 10% 15% 20% 25% 30% 100%
User set
in 1%
steps
3. Low Voltage
Cut-Off Threshold
Non-Pro-
tection
2.6V/Cell 2.8V/Cell 3.0V/Cell 3.2V/Cell 3.4V/Cell
User set
in 0.1V
steps
4. Start
Mode(Punch)
Level 1 Level 2 Level 3 Level 4 Level 5 Level 6 Level 7 Level 8 Level 9
Advanced Items
5. Max Brake Force 12.50% 25% 37.50% 50% 62.50% 75% 87.50% 100%
6. Max Reverse
Force
25% 50% 75% 100%
7. Initial Brake
Force
=Drag
Brake
Force
0% 20% 40%
8. Neutral Range 6%
(Narrow)
9%
(Normal)
12%
(Wide)
9. Over-heat
Protection
Enable Disable
10. Boost Timing 0° to 16° in 1° steps, default 0°
11. Boost Start RPM 1000RPM to 15000RPM in 1000RPM steps, default 5000PRM, Stock class specic software only
12. Boost Timing
Acceleration
50RPM/deg to 750RPM/deg in 50RPM steps, Stock class specic software only
13. Turbo Timing 0° to 20° in 1° steps, default 10°
14. Turbo Slope
Rate
3°/0.1s 6°/0.1s 12°/0.1s 18°/0.1s 24°/0.1s Fastest
15. Turbo Delay 0s/off 0.1s 0.2s 0.3s 0.4s 0.5s 0.6s 0.7s 0.8s
1-9 are manually adjustable with on/off switch | 10, 13, 14, 15 need program box to access these settings |
11, 12 need program box and rmware update to access these settings
*The Vortex R10 Race (ORI65109) has been developed for the fIxed 0-Timing class.
For this speed controller the programs 10-15 cannot be adjusted nor activated.
ORI65101-ORI65102-ORI65109*
Programmable Items
7Vortex R-Series Speed Controls
