12
ENCLOSURE DETAILS
ENCLOSURE DERTAILS
1. Parameters listed are for conventional applications only, for further help
please call Sound Pros Tech Support.
2. At least 0.75” MDF (Medium Density Fiberboard) is recommended for any
XTR enclosure.
3. Recommended enclosures are NET box volumes, speaker and port
displacement are calculated into the volume of the enclosure, you will need
to add these volumes to calculate GROSS volume for the enclosure.
NOTES
* Due to the high power capabilities and long excursion of the XTR woofers,
the Thiele/Small Parameters were calculated and measured using Klippel
analyzer system.
** Energy Bandwidth Product (EBP) is determined by the following formula Fs/
Qes=EBP. EBP values of 50 and lower suggest a sealed enclosure is best, 50 to
90 means the subwoofer versatile and 90 and above mean vented Enclosure is
recommended.
*** Subsonic lter should always be used and adjusted specically for vented
box designs.
